Promag 55S – Hygienic Electromagnetic Flowmeter
The Endress+Hauser Promag 55S is a compact, hygienic electromagnetic flowmeter designed for the food, beverage, and pharmaceutical industries. It meets the strictest hygienic standards including 3-A and EHEDG, ensuring product safety and process integrity.
Key Features
- Nominal diameter: DN8 to DN200
- Hygienic process connections: Tri-Clamp, DIN 11851, SMS, Varivent
- PTFE or PFA liner
- CIP/SIP compatible up to 150°C
- 3-A and EHEDG certified
- Accuracy: ±0.5% of reading
- Communication: HART, PROFIBUS DP, EtherNet/IP
Applications
- Dairy, beverage, and brewing processes
- Pharmaceutical and biotech manufacturing
- Food processing and CIP systems
- Cosmetics and personal care products
Technical Specifications
| Parameter | Specification |
|---|---|
| Nominal diameter | DN8–DN200 |
| Accuracy | ±0.5% of reading |
| Process temperature | –20 to +150°C (CIP/SIP) |
| Hygienic standards | 3-A, EHEDG |
| Process connections | Tri-Clamp, DIN 11851, SMS, Varivent |
| Liner material | PTFE, PFA |
| Protection class | IP67/IP69K |
| Communication | HART, PROFIBUS DP, EtherNet/IP |
