Memosens CPS12E – Digital ORP/Redox Sensor
The Endress+Hauser Memosens CPS12E measures oxidation-reduction potential (ORP/redox) using Memosens digital technology. It is ideal for monitoring disinfection processes, chemical reactions and water quality.
Key Features
- Measuring principle: Potentiometric (platinum electrode)
- ORP range: −1500 to +1500 mV
- Accuracy: ±5 mV
- Memosens digital technology
- Process temperature: 0 to +80 °C
- Process pressure: up to 6 bar
- Reference system: KCl gel, double junction
- Process connections: PG13.5, M12, Varivent
- Compatible with Liquiline CM4xx transmitters
Applications
Chlorination control, disinfection monitoring, chemical reaction control, water treatment, swimming pool water quality, industrial process monitoring.
Technical Specifications
| Parameter | Value |
|---|---|
| Measuring range | −1500 to +1500 mV |
| Accuracy | ±5 mV |
| Process temperature | 0 to +80 °C |
| Process pressure | Up to 6 bar |
| Technology | Memosens (inductive digital) |
