Cerabar M PMC41 – Compact Hygienic Pressure Transmitter
The Endress+Hauser Cerabar M PMC41 is a compact pressure transmitter with a flush-mounted ceramic sensor, designed for hygienic applications in the food, beverage, and pharmaceutical industries.
Key Features
- Measuring range: 0 to 40 bar
- Accuracy: ±0.2% of span
- Flush ceramic Al₂O₃ sensor – no dead spaces
- 3-A and EHEDG certified
- CIP/SIP compatible
- Process connections: Tri-Clamp, DIN 11851, Varivent, G1/2″
- Communication: 4–20 mA HART, IO-Link
Applications
- Dairy and beverage processing
- Pharmaceutical and biotech manufacturing
- Food processing and CIP systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Measuring range | 0–40 bar |
| Accuracy | ±0.2% of span |
| Sensor type | Flush ceramic Al₂O₃ |
| Process temperature | –10 to +150°C |
| Hygienic standards | 3-A, EHEDG |
| Protection class | IP67/IP69K |
| Communication | 4–20 mA HART, IO-Link |
